DAC-60 SDI to VGA Converter |
| Wide range conversion for great compatibility | Aluminum Alloy and Heavy Duty Design |
 |
 |
|
The DAC-60 supports 3G/HD/SD-SDI to VGA conversion, suits projector and LCD screen display really well. |
Super sturdy and durable. DAC series has a rugged metal housing for use in even the roughest conditions. Low heat dissipation, ideal for long hour operation in normal ventilated environment. |
|
Independent SDI loop through |
|
|
|
|
|
SDI loop through is unaffected by the adjustments of resolution setting to the VGA signal, users can connect the original video signal to other terminal device. |
|
Specifications |
| Conversion |
3G/HD/SD-SDI to VGA |
| Video Inputs |
1x 3G/HD/SD-SDI |
| Loop Through |
Yes |
| Video Outputs |
1x VGA |
| Supported Video Input Formats |
1080p (23.98/24/25/29.97/30/50/59.94/60Hz), |
| Output Resolutions |
1920×1200 (60Hz), 1920×1080(60Hz), 1600×1200(60Hz), 1400×1050(60Hz), 1366×768(60Hz), 1280×1024(60Hz), 1280×800 (60Hz), 1024×768 (60Hz), 800×600 (60Hz) |
| Equalizer |
Yes |
| Reclock |
Yes |
| SDI Cable Drive |
Yes |
| Dimension (LxWxH) |
112 x 85 x 45 mm |
| Weight |
0.4 kg |
| Operating Temp. Range |
0~40 °C |
| Power |
DC 12V, 3.6W |
| What’s in the Box |
1 x DAC-60 product |
Workflow |
 |
Gallery |
|
|
 |
 |
