HS-2850 HD/SD 8/12-Channel Portable Video Studio |
| A complete and professional studio made for big events. | Ideal for large-sized live video productions. |
 |
Supports up to 12 HD or SD inputs in a variety of configurations, 3 SDI and 1 HDMI freely assignable outputs. Create impressive video effects to enhance your production.
|
|
This professional studio includes a built-in switcher, intercom, tally, audio delay and monitor. |
2 x PIP and 2 x DSK assignable for luma key or alpha key. |
| 17.3” LED Backlit Monitor | Build in Intercome System |
 |
 |
|
Built-in Monitor Display. 17.3” HD TFT LED backlit monior with resolution 1920×1080 pix. |
Built in 8 Channel Intercom/Talkback system (4 x belt packs supplied) |
Supports multiple inputs and output configurations |
|
 |
|
|
Supports one 4K HDMI input, one 12G SDI input, and three 3G-SDI input as well as video outputs with embedded audio. |
|
| 2 x XLR Analogue Audio Inputs and 2 x XLR Analogue Audio Outputs | Easy post-edit and playback |
 |
 |
|
Audio input can be embedded into the video for output playback thus making HDR-80 the device for live event broadcast. |
Compressed videos are saved on two 2.5″ SSD drives. If one disk is full, the recording will automatically continue on the second disk. It’s easy to expand storage for continuous recording. (Support Samsung 860 Pro SSD only) |
| Built-in title overlay | Perfect lip sync |
 |
 |
|
Add custom graphics to help tell your story with the built-in title overlay system. |
The SE-2850’s included audio-delay feature ensures that you’ll be able to keep your audio and video perfectly in sync with one another. This means zero lip sync issues for your professional production. |
| Assignable Crosspoints | Real-time clock featuring HH:MM:SS on the multi-screen |
|
The SE-2850’s inputs can be reassigned, giving you more flexibility while organizing the multi-view interface. Supports 12 HD or SD Inputs in a variety of configurations
|
 |
|
HD Mode: (1) 12 HD-SDI , (2) 9 HD-SDI + 3 HDMI SD Mode: (1) 12 SD-SDI , (2) 9 SDI + 3 HDMI |
Count down counter MM:SS |
Specifications |
| Video Standard |
HD & SD |
| Video Format |
1080p 25/29/30/50/59.94/60Hz |
| Input Routable / Crosspoint |
All 12, repeatable |
| Video Input |
Standard: 8x SDI, 2x HDMI |
| Computer Graphic Interface |
Max 3 via HDMI |
| Down-converted Output |
3x SDI |
| Video Output |
3x SDI assignable: PGM, PVW, AUX & Clean Out 1080i 50/59.94/60Hz |
| Audio Input |
4x Balanced XLR |
| Audio Output |
2x Balanced XLR |
| Embedded Audio Support |
Input up to 16 channels, |
| Audio Delay Calibration |
Up to 8 frames |
| A+V Switching |
Yes |
| USK |
N/A |
| DSK |
2, support Lumakey & Linear key (Key / Fill) |
| Picture in Picture |
2 |
| Logo Insertion |
2 (or 1 logo + 1 clock) |
| Title Creator |
Yes, CG-200 software free download |
| Built-in Audio Mixer |
N/A |
| Built-in Monitor Display |
17.3” HD TFT LED backlit, 1920×1080 pix |
| Built-in Intercom & Tally |
8 channels (4 belt-packs incl.) |
| Special Features |
Built in TC-200 CG interface |
| Dimension (LxWxH) |
455 x 355 x 134 mm |
| Weight |
18.7 Lbs (8.5 kg), Reinforce Plastic Case |
| Power |
DC 12V, 6A |
| Operating Temp. Range |
0~40 °C |
| Options |
CB-22H/23H/46/47/60/61/62 |
| What’s in the Box |
1 x HS-2850 Unit |
